Market-leading print speeds

The FX-890IIN offers an improved USD (ultra speed draft) speed of 735 characters per second at 12 characters per inch, making a real difference to high-volume print runs such as stock reports and large batches of invoices or freight documents.

Outstanding reliability

Epson's dot matrix technology is already mature and very reliable, and these new printers improve the mean time between failure by 25% to 25,000 power-on hours, ideal for challenging conditions or where regular maintenance is not practical.

Modern design

Epson's new range of dot matrix printers have a refreshingly modern design to fit in with your working environment.

Network capability

This is a network model which supports both serial and Ethernet connections for enhanced connectivity.

Features

• Network dot matrix printer
• Market-leading print speeds Complete high-volume print runs even faster
• Very low TCO Cheap, long-lasting consumables and low power use
• Even better reliability Improved by 25% to 25,000 power-on hours
• Modern design Fits with your working environment
• Network capability Supports both Ethernet and serial connections

Specifications:

Printing Method: Impact dot matrix
Number of Pins: 9 pins
Number of columns: 80 columns
Pins: 18 Needles (2 x 9)
Power consumption: 55 Watt, 10 Watt (standby)
Supply Voltage: AC 198 V - 264 V
Product dimensions: 414‎ x 375 x 177 mm (Width x Depth x Height)
Product weight: 7,2 kg
Mean Time Between Failures: 25.000 hours
Print Head Life: 400 Million Strokes/Wire

Print

Printing Speed: HighSpeed-Draft: 10 cpi: 612 chars/s, Draft: 10 cpi: 463 chars/s, NLQ: 10 cpi: 115 chars/s
Barcodes: Coda bar (NW-7), Code 128, Code 39, Industrial 2 of 5, Matrix 2 of 5, POSTNET, UPC-A, UPC-E
Carbon Copies: 6 plus one original
Character Sets: 42
Character Tables: PCAPTEC, PC437, PC708, PC720, PC850, PC858, ISO-8859-1, Roman 8, Italic
Printing Resolution: 240 x 144 DPI

Paper / Media Handling

Document Feed: Single sheet front and rear, Continuous media front and rear, Paper output rear
Paper Formats: Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer), Envelopes, Cardboard
Paper Thickness Continuous Paper: 0,46 mm
Paper Thickness Label Base Sheet: 0,46 mm
Paper Thickness Multi Part: 0,12 mm - 0,46 mm
Paper Thickness Single Sheet: 0,06 mm - 0,14 mm

Interface ports

• USB - compatible with USB 2.0 specification
• Bidirectional parallel
• Ethernet interface (100 Base-TX / 10 Base-T)
